 BobCAM for SolidWorks™
BobCAD-CAM Inside SolidWorks™
BobCAM for
 SolidWorks™ is the latest SolidWorks
Gold Partner in CNC machining technology integrated as an Add-In inside of SolidWorks™ creating 2-, 3-, 4- & 5-axis toolpath and G-code programs
for your CNC Machine Tool.
BobCAM gives you special machining wizards for all of the milling strategies which removes the guesswork from programming. The latest PRO
level modules feature a new High Speed  Adaptive
Roughing toolpath strategy along with 4- & 5-axis PRO Full machine simulation allowing you to use your machines kinematics for realistic
multi-axis posting and simulation support. Aside from providing you standard 2-axis machining capabilities and multi-tool drilling capabilities,
the latest BobCAM for SolidWorks™ add-ons are now available for 3-, 4- and full 5-axis simultaneous CNC Milling. Each level is modular allowing
you to grow into new technology on a need to use basis.
The system combines ease of use with powerful 2-, 3-, 4- and 5-axis machining features for CNC milling, 2-axis turning and allows you to
manage each operation in a new CAM Tree. Available features Include…
- Stock Wizard, CAM Job Tree, Tool Crib & Holder Library
- Tool & Material Database
- Available 2-, 3-, 4- & 5-Axis Toolpath Wizards & CNC Milling
- Multi-Axis High Speed Adaptive Roughing
- Full Machine Simulation
- Built-In G-Code editor
- Customisable Post Processing
- RS-232 Communications & DNC Capabilities.
2-Axis Machining
BobCAM 2-Axis features include:
- Hole Drilling & Pocketing
- Profiling & Engraving
- V-Carve, Chamfer & Face Milling
- Plunge Roughing
- Associative Toolpaths
- Automatic Toolpaths
- Automatic G-Code Programming
- RS 232 and DNC Communications
|
3-Axis Machining
BobCAM 3-Axis features include:
- Z-Level Roughing & Finishing
- Slice Planar, Spiral & Radial Toolpath
- 3D Engraving
- 3D Plunge Roughing
- Complete CAM Tree
- Toolpath Boundary Containment
- 2- & 3-Axis Simulation
|
Multi-Axis Machining
BobCAM 4- & 5-Axis features include:
- 4-Axis Indexing, Wrapping & Rotary
- 5-Axis Indexing & Trimming
PRO versions include:
- 4-Axis Simultaneous
- 5-Axis Simultaneous
- Undercut Toolpath
- Flow Toolpath
- Parallel Cuts
- Cuts Along a Curve
- Morph Between 2 Curves
- Parallel to Multiple Curves
- Project Curves
- Morph Between Surfaces
- Full Machine Simulation
|
|
